Endless Turned Round Belts manufactured from a homogeneous strand or cord, wound endlessly and spliced into a seamless belt without any increase in diameter at the splice.
For special applications, in-house technologies allow the internal splice to be vulcanized or produced with a special splice design, increasing tensile strength by up to 60%.
For elastic belt types, the core is welded. Due to their unique construction, these belts offer exceptionally smooth running characteristics and outstanding flexibility. This allows for minimum pulley diameters as low as three times the belt diameter and, for certain belt types, operating speeds of up to 70,000 rpm. Despite this, the belt speed should not exceed 60 m/s.
Manufacturing the cords ourselves in our in-house twisting facility, we can adjust our manufacturing process to virtually any customer requirement, regardless of diameter or whether monofilaments, multifilaments, films, or multi-component yarns are used.
The square profiles of our Vulkollan round belts are machined from 40 kg material blocks, ensuring outstanding quality throughout the entire production process from raw material to finished product.

Our one of a kind computer controlled machines are able to manufacture products precisely from diameters as small as 0.8 mm.
Continuous product development and close collaboration with our customers enable us to constantly adapt our products to changing operating conditions or develop entirely new belt types according to customer requirements.
Textile belt types can be impregnated with a wide variety of coatings to protect against abrasion, increase the coefficient of friction, or achieve specific performance characteristics.
Special thermal setting processes ensure lowest possible operational elongation of low-elongation belt types throughout their service life.

When selecting the right belt type, we are happy to advise you and support you with new designs and technologies based on decades of experience.
Elastic Types:
- PU,
- Vulkollan
Semi-elastic Types:
- PA.6
- Set-Polyester
- Nylon HE
Low Elongation Types:
- Polyester
- Nomex
- Nomex-PTFE
- Polyester-PTFE
- Kevlar/Twaron
- PA.6 antistatisch
- PBO
Note: For semi-elastic types, we recommend the use of a tensioning device. For low-elongation types, a tensioning device is mandatory.
| Available Diameters: | 0.8 – 15 mm |
| Available Lengths: | 120 mm – 50,000 mm |
| Temperature Resistance: | -50°C to +480°C |
| Coefficient of Friction: | 0.05 µ – 0.4 µ * |
| Maximum Tension: | < 500 N |
All specifications may vary depending on the belt type and material used.
* According to Pflug test specification SPPN 91.001, measured on polished V2A stainless steel.
